35MM FILM EQUIVALENT FOCAL LENGTH
Angle of view (horzntl, vertl, diagnl)
3°30', 2°20', 4°10'
Lens construction (elements/groups)
16/12
No. of diaphragm blades
9
Minimum aperture
32
Closest focusing distance (m)
4.5
Maximum magnification (x)
0.15
Distance information
Provided
Image stabilizer
4-stops
AF actuator
Ring USM¹
Dust/moisture resistance
Yes
Filter diameter (mm)
52 Drop in
Max. diameter x length (mm)
168 x 448
Weight (g)
3920
Magnification - Extension Tube EF12 II
0.17-0.02
Magnification - Extension Tube EF25 II
0.20-0.05
LENS CAP
Lens hood
ET-160 (WII)
HARD CASE
Soft case
Lens Case 600B
G.F.Holder III (hood III*)
NC¹
G.F.Holder IV (hood IV*)
NC¹
Extenders EF1.4x II and EF2x II
Compatible
Disclaimer
*Maximum number of Hood III/IV attachable. In case of zoom lenses, the maximum number applies to the short focal length
Footnote
¹ Full time Manual focus
¹ Use 52mm drop in filter holder
¹ Use 52mm drop in filter holder
