OPTICAL FEATURES/SPECIFICATIONS
Image size
-
35mm film equivalent focal length (mm)
-
Angle of view (horzntl, vertl, diagnl)
74º - 19º 20', 53º - 13º, 84º - 23º 20'
Lens construction (elements/groups)
17/13
No. of diaphragm blades
7
Minimum aperture
22-32(36)¹
Closest focussing distance (m)
0.4
Maximum magnification (x)
0.3 (at 105mm)
Distance Information
Yes
Image stabilizer
4-stops
AF actuator
STM
PHYSICAL SPECIFICATIONS
Dust/moisture resistance*
-
Filter diameter (mm)
77
Max. diameter x length (mm)
83.4 x 104
Weight (g)
525
ACCESSORIES
Lens cap
E-77U / E-77II
Lens hood
EW-83M
Lens case/pouch
LP1219
Rear cap
Lens Dust Cap E
Magnification w/ Extension Tube EF12 II
0.61-0.46
Magnification w/ Extension Tube EF25 II
0.67-0.27¹
Extender Compatiblity
Not Compatible
Other Accessories
Close-up lens 500D Compatible for telephoto only
Magnification: 0.41 – 0.21x at 105 mm
Disclaimer
*Lenses with dust/moisture resistance are fitted with a rubber ring on the lens mount which may cause sligth abrasion of the camera mount.
This in no way effects either the lens or camera performance.
Footnote
¹ Minimum aperture if using 1/3stop increments
¹ Not Compatible at wide angles
