DigiDot drop-on-demand, piezoelectric
Water based dye and pigment, InkSafe™ technology (contact your local sales representative for details)
Variable, 5–12 picoliter
Next generation look & feel user interface
Pinless, tight web, automatic tension control
Tight web unwinder (included in basic unit)
Open post-processing interface with Type1 connectivity
1200 dpi perceived image quality with 600 × 600 dpi and Multilevel
Simplex configuration: 2-up simplex
I-Twin / L-Twin / H-Twin: 2-up duplex
Simplex configuration: 324 / 505 / 675 / 857
I-Twin / L-Twin / H-Twin: 648 / 1,010 / 1,350 / 1,714
Simplex configuration: 2-10 / 3-16 / 5-22 / 6-28
I-Twin / L-Twin / H-Twin: 5-21 / 7-33 / 10-44 / 12-56
6.5"-21.25" (165-540 mm) (ColorStream 3500 / 3700 / 3900)
6.5"-17" (165-432 mm) (ColorStream 3200 / 3500 / 3700 / 3900)
6"- 54"
6.5"-21.25"
Simplex configuration: not applicable
I-Twin / L-Twin / H-Twin: 6.5"-21.25"
60–160 gr/m2
Preprinted, inkjet, laser and recycled newspaper
70 mm, 3", 5" and 6"
Simplex configuration: 7,460 mm
I-Twin: 11,950 mm
L-Twin: 10,700 mm
H-Twin: 8,500 mm
Simplex configuration: 2,500 mm
I-Twin: 2,500 mm
L-Twin: 8,840 mm
H-Twin: 8,500 mm
1,900 mm
Simplex configuration: 2,500 kg
I-Twin / L-Twin / H-Twin: 5,300 kg
Simplex configuration: 33 kW
I-Twin / L-Twin / H-Twin: 33 kW (2 connections)
Optimal range 20–26 °C, limited range 16–29 °C
Optimal range 40–60%, limited range 30–80%
Maximum 75 dB
SRA MP third-generation, high-performance blade processors
AFPDS, PDF, PCL , Line Data* , LCDS*, Metacode*, PostScript*, PPML*, TIFF*, VIPP*
* Via PRISMAproduction
PRISMAproduction®
Gigabit Ethernet
Simplex configuration: 1/0–6/0
I-Twin / L-Twin / H-Twin: 1/1–6/6
Available for all configurations.
Available for all configurations.
Available for all configurations.
Available for all configurations.
Available for all configurations.
Available for all configurations.
Available for all configurations.
Available for all configurations.
